Worry-Free Kitchen Sealed Lithium Battery Power Smoke CO Alarm P3010K-CO
Ideal for the kitchen with 10-year sealed lithium battery and smoke and CO sensing technologies work together to detect real fires faster and reduce cooking-related nuisance alarms ✔️
✅ Hassle-free protection - Goodbye late night low battery chirps! Never replace a battery during the alarm’s operating life and no need to worry about the batteries being removed
✔️
✅ Always on - Sealed-in lithium battery powers alarm for 10 years - the life of the alarm.
✔️
✅ Save money - Save up to $40 over the life of the alarm (battery costs).
✔️
✅ Model #: 21009667
✔️
✅The right alarm, the right location. Each of the four smoke alarms includes features designed to address location-specific safety needs, such as an LED light in the hallway.
The Kidde P3010K-CO is a 10-year, sealed battery, smoke and carbon monoxide alarm that features photoelectric and electrochemical sensing technology with Smart Hush feature. This combination alarm combines the detection capabilities of a photoelectric sensor with that of an electrochemical sensor, which is used to detect CO. When either sensor notices a potential hazard, it will communicate with the other. Depending on what is detected, the alarm will adjust its smoke sensitivity in order to better discriminate between a real hazard and a false one.
This constant communication enhances the alarm’s overall performance and significantly reduces the potential for a nuisance alarm. The sealed in lithium battery will power the unit for the entirety of its 10 year life, eliminating the need for battery replacement and worry about unauthorized battery removal. The alarm provides continuous protection smoke and carbon monoxide, even during power outages. The alarm will automatically activate when it is attached to the mounting bracket; there are no pull-tabs, no switches, everything is automatic. At the end of alarm life, the unit will chirp, indicating the alarm is in need of replacement. The customer can use a simple tool such as a screwdriver to deactivate the unit, stopping the chirp and making it safe for disposal. Industry experts (such as the NFPA), recommend that both ionization and photoelectric smoke alarms be installed to help insure maximum detection of the various types of fires that can occur within the home. Ionization sensing alarms may detect invisible fire particles (associated with fast flaming fires) sooner than photoelectric alarms. Photoelectric sensing alarms may detect visible fire particles (associated with slow smoldering fires) sooner than ionization alarms.
Kidde Worry-Free Kitchen Smoke & Carbon Monoxide Alarm
Part Number(Ordering Number):2100966
Features
Combination Smoke and Carbon Monoxide Alarm – Smoke and CO sensing technologies work together to detect real fires faster and reduce cooking-related nuisance alarms.
Sealed-In Lithium Battery – Sealed-in lithium power supply; no battery replacement required over the 10 year life of the alarm. Eliminates worry about battery removal or unauthorized deactivation of alarm.
Photoelectric Sensor – Smoke alarm contains advanced photoelectric sensor that may detect visible particles (associated with smoldering fires) sooner than ionization alarms.
Self Activation – Alarm automatically activates when attached to the mounting bracket.
Alarm Memory – Rapidly flashing LED alerts user if the alarm has sounded since the last time the test/reset button was used.
Test/Hush Button – Tests alarm circuitry and activates Hush features.
Smart HushTM – Temporarily silences nuisance alarms for approximately 10 minutes and will not allow hush mode unless the unit is in alarm mode.
LED – Red LED will blink in conjunction with the alarm sound.
End of Life Warning – Alarm chirps every 30 seconds to indicate the unit is in need of replacement.
End of Life Hush® – End of life indication can be silenced three days at a time up to 30 days to allow for alarm replacement at a more convenient time.
UL217 and UL2034 Listed
10 Year Limited Warranty
Technical Specifications
Model | P3010K-CO |
PowerSource | Sealed Lithium Battery |
Sensor: | Smoke: PhotoelectricCO: Electrochemical |
Audio Alarm | 85dB at 10ft |
Temperature Range | 40 ̊F (4.4 ̊C) to 100 ̊F (37.8 ̊C) |
HumidityRange | 10%-85% non-condensing relative humidity (RH) |
Size | 5.22” in diameter x 1.6” depth |
Weight | 1 lb. |
Interconnects | No |
Warranty | 10 year limited |
Architectural and EngineeringSpecifications
- The combination smoke and carbon monoxide alarm shall be Kidde model number P3010K-CO or approved equal. It shall be powered by a non-replaceable lithium battery with a 10-year life. The lithium battery shall be sealed in the unit to prevent removal and/or tampering. The unit shall incorporate a photo-electric smoke sensor and an electrochemical carbon monoxide sensor. The CO sensor shall be of a fuel cell design and provide accuracy of +/- 20% + 15 PPM. The temperature operating range shall be between 40ºF and 100ºF (4ºC and 38ºC) and the humidity operating range shall be 10%-85% non-condensing relative humidity.
- The alarm can be installed on the surface of any wall or ceiling following the UL/Manufacturer’s approved placement guide-lines. The alarm shall incorporate an automatic activation fea-ture that will activate the unit as soon as it is attached to the mounting bracket, no other steps are involved.
- The alarm shall include a test button that will electronically simulate the presence of smoke and CO and cause the unit to go both modes of alarm. This sequence tests the unit’s electronics to ensure proper operation.
- The CO sensor will not alarm to levels of CO below 30 PPM and will alarm in the following time range when exposed to the cor-responding levels of CO.
70 PPM CO Concentration60 – 240 Minutes
150 PPM CO Concentration10 – 50 Minutes
400 PPM CO Concentration4 – 15 Minutes
- The alarm shall include a piezoelectric horn that is rated at 85 decibels at 10 feet. For a CO incident, the horn will sound in the repetitive manner – four (4) fast beeps, a short pause, four (4) fast beeps, a short pause. In a smoke incident, the horn will sound in the repetitive manner – three (3) beeps, a pause, three (3) beeps, a pause. The red LED will flash in conjunction with the alarm sound.
- The unit shall indicate a low battery condition with a brief alarm chirp and LED flash once every 30 seconds. In standby condi-tion, the LED will flash every 60 seconds for the first 10 minutes following power on or test, and once every 10 minutes thereaf-ter. It will also flash every 10 seconds while in Hush mode.
- The smoke alarm shall include an End of Life Alert, where ten years after initial power-up the unit shall chirp two times every 30 seconds to indicate the alarm needs to be replaced. The End of Life indication can be silenced for 3 days at a time for
