PRESSURE SWITCH PS10-1

Manufacture: Tyco

Product code: PS10-1

Low Pressure Sw ❌
✅ 0.27-1.03bar ❌
✅

Product information

Pressure switch PS10-1 is designed to detect water condition in automatic fire extinguishing systems by special design such as wet piping system with alarm check valve, dry pipe, pressure relief valve or overflow valve. PS10 is also suitable for providing low pressure monitoring signals; adjustable 4 to 15 psi (0.27 and 1.03 bar).

PRESSURE SWITCH PS10-1

1. PRODUCT INFORMATION PRESSURE SWITCH PS10-1

- As Potter flow switch used for steel pipe, usually suitable for diameter 50mm-200mm - Original box

- Dimensions: (9.6cm) 3.78" W x (8.1cm) 3.20" D x (10.7cm) 4.22" H - Seamless cast of red powder with solid structure, suitable for rainwater environment...

- Pressure connection: Nylon 1/2" NPT - Adjustment : 0.27 - 0.55 BAR (4 - 8 PSI) - Difference: 0.13 BAR (2 PSI)

- Maximum system pressure: 17.2 BAR (250 PSI)

- Switch contact: SPDT (Form C) ; 10.1 Amps at 125 / 250VAC, 2.0 Amps at 30VDC - One SPDT in PS10-1, two SPDT in PS10-2

- Temperature: -40°C to 60°C (-40° - 140°F)

2. ADVANTAGES OF PRESSURE SWITCH PS10-1

The POTTER pressure switch offers the following advantages:

• High contact load

• Extremely short response time

• Good anti-vibration

• Long operating life

• Can be used for both liquids and gases

• Small size - Easy to fit the plate

3 . STRUCTURE OF PRESSURE SWITCH PS10-1

Structure of pressure switch ps10-1

4. INSTALLATION OF PRESSURE SWITCH PS10-1

This series Potter pressure switch must have two duct entrances one for each switch compartment separately to facilitate use. the voltage is not the same for each individual switch. The adapter cover shall be zinc die-cast for rain protection and fitted with an anti-corrosion screw. NS Pressurized water flow converter must be suitable for indoor or outdoor service with NEMA 4/IP66 rating. Pressurized water flow adapter must be UL Ulc and CSFM listed, FM and LPC approved and NYMEA approved.

Cách lắp đặt công tắc áp suất PS10-1
