OSID-DE, Visual Smoke Detector
OSI-10, OSI-90, OSE-SP, OSE-SPW, OSE-HPW, OSE-HP-01 Open Area Imaging Smoke Detector (OSID) provides beam smoke detection technology, By using Using advanced dual-wavelength beam and optical imaging technology for early warning smoke detection, OSID provides a low-cost, reliable, and easy-to-install solution for overcoming beam detection problems typical problems such as false alarms and alignment difficulties.
- Maximum detection range 150 m (492 ft) for OSI-10
- Maximum detection range for CPR approved products is 200 m (656 ft)
- LED dual wavelength based smoke detection
- Optical imaging with CMOS imaging chip
- On-board event log for fault diagnosis and alarms
- Tolerance to false alarms due to construction movement
- High resistance to dust, water vapor and ingress of solid objects
- Easy alignment with large adjustment and viewing angle
- No need for precise alignment
- Tolerance of drift
- Auto start in under ten minutes
- Simple DIP switch configuration
- Simple and easy maintenance requirements
- Three selectable alarm thresholds
- Status LEDs for Fire, Problem and Power
- Common alarm interface for simple fire system integration
- Large, open spaces where highly sensitive detection is not a priority but reliable, easy detection is essential, including:
- Airport
- Train station
- Mall
- Stadium
- Hotels, convention centers and office buildings/complexes
- Entertainment venues
- Warehouse and production floor
Standard certificate - UL - ULC - FM - CE - EMC and CPR - VdS - ActivFire - BOSEC - NF (AFNOR) - VNIIPO
