Carbon Dioxide (CO 2) Fire Extinguishing System
⭐Spain Imported Airfire Fire Extinguisher, it's the most effective gas to suppress a wide range of fires, Class A, B and C.
DESCRIPTION
+ Features
- Colorless and odorless
- Chemical inert
- Non-conductive
- No residue when flushing
- Easy to refill for use
- Low cost for uninhabited areas
+ Fire fighting mechanism
- Shift the oxygen content in the atmosphere, reducing the oxygen concentration 21% to 15% (for most applications).
- Effective cooling by removing enough heat the fire.
.jpg "Hệ thống Chữa cháy Carbon Dioxide (CO 2 ), Thiết bị chữa cháy Airfire Tây Ban Nha")
+ Method of application
- Total anti-flooding application: includes discharging a certain amount of carbon dioxide a fixed tank at a specified concentration.
- Local application: when the fire hazard is relatively small compared to the volume of the enclosure, it is more effective to discharge CO2 directly on a surface type and potential fire.
+ Typical hazards protected - Including but not limited to:
- Marine industries: engine rooms, paint cabinets, vehicle handling areas on cargo ships, flammable liquid storage areas.
- Heavy industries: rolling mills, control rooms, sheet printing, chipboard cutters, cable trays, electrical rooms, motor control centers, nuclear power facilities, waste storage facilities, etc.
System parameters
The complete high pressure system (57 bar @ 20 ºC) uses a 67 liter cylinder with all necessary components, all that is missing is piping and installation. Depending on the risk(s) to be protected, different configurations can be designed:
Modular system (single cylinder configuration)
Banking system (multi-cylinder configuration)
Selector valve system (a system configured to protect different risks)
Check out its key features:
Compact valve technology: allows the use of standard cylinder transport safety caps, avoiding the use of special caps and adapters. Direct release circuit: connect output to actuate auxiliary cylinders master valve, remove pilot cylinder and drain screw (except selector valve configuration).
Safest maintenance: all parts can be assembled and disassembled while under pressure, including: pressure gauge, pneumatic release, manual release and solenoid valve.
Zero discharge operating system: while performing system function test during operation, the release circuit can be disconnected the valves to avoid any accidental discharge and allow testing easy.
Stand strong and secure: stand-alone or wall-mounted with several configurations available, adapting the system to the space of the room.
Flexible and resistant: all exhaust and exhaust manifolds account for the best balance between flexibility and durability, allowing for easy installation and durability to stand the test of time.
Free spare parts: when discharging or during maintenance, there is no broken disc, nor special component replacement. Reduce down time and reduce storage costs.
Differential pressure drive: allows the same pressure the cylinder to be used to maintain valve closure, reducing leakage problems significantly even during high temperature fluctuations.
Optimized system standardization: common components between systems reduce the quantity needed thereby saving warehousing costs and enabling fast delivery to customers locally.
STANDARDS AND CERTIFICATE
Design CO2 fire fighting projects according to mandatory standards:
- NFPA 12: 2011
- CEA4007
- APSAD R13
