Tyco Horizontal Nozzle TY5337

Manufacture: Tyco
Product code: ty5337

Standard Response, 11.2 K Factor Nozzle Flow, Extended Coverage Nozzles, UL, C-UL, and NYC standards, Contact us now 0917911114 for a quote on CO2 fire suppression systems, Nozzles Viking VK536, VK 5222..

Zalo

Consulting hotline: 0944934114
Product information

Tyco Horizontal Directional Spray Head TY5337 (TYCO Model SW-24), 11.2 K-Factor spray flow, standard extended response sprinkler covering Ordi-nary Hazard (ECOH) Sprinklers, bulb nozzle decoration is designed for use in normal hazardous situations per NFPA 13. SW-24 provides protection of coverage areas up to 16 ft x 24 ft (384 ft2), compared to standard Horizontal spray head has a maximum coverage area of 10 ft x 10 ft (100 ft2) for general hazardous occupations.

The TY5337 Horizontal Directional Tyco Nozzle is designed to be installed along the wall or side of a beam and is simply used instead of a standalone or vertical nozzle due to aesthetic or building construction considerations, where pipes in the ceiling are undesirable. Anti-corrosion coatings, if applicable, are used to extend the life of allo copper The sprinklers go beyond anything else that can be obtained contact with corrosive spheres. Although anti-corrosion coating nozzles have passed the standard corrosion tests of grant approval agencies, this test is not representative of all cor-rosive atmospheres. Therefore, the end user should consult the suitability of these anti-corrosion coatings for any corrosive environment. The effects of ambient temperature, chemical concentration and gas/chemical velocity, should be considered to a minimum, along with the corrosive nature of the chemical to which the nozzles will be exposed.

Tyco Horizontal Nozzle TY5337

Specifications of Tyco Horizontal Nozzle TY5337

- Meets standards: UL, C-UL, and NYC

- Maximum working pressure: 175 psi (12.1 bar).

- Injection coefficient: K=11.2 GPM/psi½ (161.3 LPM/bar½).

- Nozzle size: 3/4 inch NPT (DN20).

- Size of glass tube: 3mm

- Trigger temperature: 200 °F (93 °C) Green glass tube

- The maximum coverage area is up to 29.7 m², larger than the specified 9.3 m2 in hazardous environments normally for horizontal nozzles. - Has a protective coating to prolong the life of the nozzle when using the nozzle in corrosive environments. - Plating material: Brass, Cr.
