Lightning arresters RS-485
Lightning arrester price, RS-485 is an extremely intelligent lightning protection device, providing all kinds of genuine and effective lightning protection devices, Household electrical surge arresters, 3-phase surge arresters, Aptomat against lightning Lightning, Surge arresters, Catalog of surge arresters Schneider,How to choose surge arresters
Infomation:Lightning arresters RS-485
Surge protection is when a lightning strike hits the ground, it senses electromagnetic wires, nearby data lines, etc. (In theory, the radius of the sensor is 2Km the location of the Lightning strike). This will cause expensive equipment damage.
Therefore, in addition to direct lightning protection, lightning spreading will help the electrical, electronic and IT systems to protect the maximum dangers caused by lightning. Electrical, electronic and IT equipment are usually protected lightning
The -06D3 is designed to protect the lightning terminals the terminals connected to the RS-232 control data transmission line. CITEL B180-06D3 RS-485 lightning arresters
Block units are designed for wall mounting and screw-type connections.
These boxes support all three types: 1, 2 and 4 pairs of strings. The circuit board can be removed for easy maintenance (the boards are called S180, S280, S480 ...).
Existing models of protection for RS-485 data lines:
B280-06D3: Lightning protection for 2 lines (2pair) RS-485 signal
B180-06D3: Lightning protection for 1 line (1pair) RS-485 signal
B480-06D3: Lightning protection for 4 lines (4pair) RS-485 signal
Characteristics:Lightning arresters RS-485
- These lightning protection devices can protect both the data link and the RS control signal
- Overvoltage protection for 1, 2 or 4 pairs of wires
- Easy connection
- Removable protection board
- Mounting on the wall and screw connection
Technical parameters:
You will receive a quote from us as soon as possible..
