HD Fire M 241 Stainless Steel Water Spray Gun
Monitor – M 241 (Stainless Steel) is a stainless steel water gun manufactured by HD Fire
✅ 100% genuine
✅ Effective use with Viking HV14 and HV 17 nozzles
✅ Genuine warranty commitment
✅ Contact us now 0917 911 114 get free consultation 24/7
Detailed Description HD Fire, M 241 Stainless Steel Water Spray Gun
The HD Fire, M 241 Stainless Steel Water Gun is corrosion resistant, durable, manually controlled for permanent installation as well as trailer mount. Commonly used to protect flammable liquid storage tanks, load racks, sea dikes and many other industrial applications. The HD Fire, M 241 Stainless Steel Water Spray Gun possesses a number of design features that make it easy to operate, minimal maintenance, and resistant to common destructive environments. They are used with sprinklers, non-aspirators and sprinklers with flow ranges up to 600 GPM (2270 LPM).
HD Fire, 2.5 inch (65MM) M 241 Stainless Steel Water Spray Gun. Vertical and horizontal rotation is through stainless steel swivel joints with two rows of stainless steel bearings. Both vertical and horizontal movements are controlled by the handle with twist lock. Capable of heavy traffic and can be operated manually by a single firefighting aircraft. The design ensures that counter-reaction forces are prevented affecting the horizontal and vertical position of the screen. No counterbalance is required to compensate for the weight of the nozzle.
HD Fire, the M 241 Stainless Steel Water Spray Gun is capable of 360 degrees. Continuous horizontal rotation and elevation angle +90 degrees. above horizontal and 45 degrees. below is horizontal. The water valves in the exhaust manifold reduce turbulence and loss of friction thus increasing nozzle efficiency to achieve greater range. To ensure the desired performance, the friction loss through the screen must be considered while selecting the nozzle and the flow through the gun with reference to the base pressure available at the inlet of the screen.
Specifications HD Fire, M 241 . Stainless Steel Water Spray Gun
- Model : M 241
- Structure: stainless steel
- 63 mm (2.5") waterway, 65, 80 or 100 mm (2.5" 3" or 4") flanged inlet and 2.5" BSP male threaded outlet
- Vertical and horizontal movement by handle and manual lock
- Copper or stainless steel coupling with two rows of stainless steel bearings and grease fittings
- 360° continuous horizontal rotation and vertical elevation +90°, -45°
- Maximum operating pressure 12 bar (175 psi).
- Input connections: 2.5”, 3” OR 4” (65, 80, OR 100NB) Flange to ANSI B16.5 # 150, R.F.
- Output connection: 2.5” BSP (M)
- Weight: 31 Kg Flows up to 2270 lpm (600 gpm) with less than 10 psi . friction loss
You will receive a quote from us as soon as possible..
