Eversafe Trolley Foam Fire Extinguisher
MFG-45,MFG-135,MFG-150 Eversafe portable Trolley Foam Fire Extinguisher Capacity 45 liters, 135 liters and 150 liters EVERSAFE AFFF foam fire extinguisher type of fire extinguisher The mobile is certified to BS EN 1866 and manufactured according to an ISO 9001 Certified Quality System. It is designed to protect people and property in high-risk areas where there is always a possibility. the possibility of a large-scale fire. Portable units have significantly greater extinguishing capacity than portable extinguishers, and are highly maneuverable and can be easily operated by only one person.
The Eversafe Trolley Foam Fire Extinguisher is effective on Class B hydrocarbon fuel fires such as oil, petroleum, aviation fuels, and is particularly suitable where rapid knockdown is required. AFFF Foam is compatible with all dry powders. Its excellent wetting properties make it useful in class A fire protection. It is recommended for use in refineries, airports, boats, chemical plants, offshore platforms, homes. garages, warehouses, farms and heavy production areas.
Advantages Eversafe Trolley Foam Fire Extinguisher
Designed to protect people and property in high-risk areas where large-scale fires occur.
- Recommended for airports, ships, chemical plants, offshore platforms, heavy manufacturing area garages, refineries, warehouses, power plants, etc.
- Significantly greater extinguishing capacity.
- Highly maneuverable and can be easily operated by a single person. Tested and certified to BS EN1866, Pressure Equipment Directive (PED) and Marine Equipment Directive (MED).
Specifications Eversafe Trolley Foam Fire Extinguisher
Model | MFG-45 | MFG-135 | MFG-150 |
Type | like a gas tank | ||
Capacity(liter) | 45 | 135 | 150 |
Fire extinguisher | AFFF foam (pre-mixed) | ||
Extinguishing | AFFF foam (pre-mixed) | ||
Valves/Headcap | brass | ||
CO2 Box | 1kg | 2kg | 2kg |
Faucet size | 16 mm x 6 m | 19 mm x 6 m | 96 mm x 6 m |
Chassis | Square steel | ||
vật liệu | Steel | ||
Tank diameter(mm) | 386 | 552 | 552 |
Height(mm) | 980 | 1395 | 1450 |
Width (mm) | 567 | 685 | 685 |
Deep (mm) | 670 | 930 | 930 |
Tank weight(kg) approx | 52 | 108 | 118 |
Bottle+foam weight (kg) approx | 97 | 243 | 268 |
Working temperature range | + 5 ° C to + 60 ° C | ||
Working pressure (20°C) | 12 bar | ||
Test pressure | 21,5 bar | 22,5 bar | 22,5 bar |
Safety valve lifting pressure | 18-20 bar | ||
Thời gian xả (giây) | 162 | 282 | 368 |
Phạm vi xả (m) | 10-12 | 11-13 | 11-13 |
Fire rating/Class | A IIB | A IVB | A IVB |
Sơn trong bình | Epoxy cao cấp | ||
Sơn bề mặt ngoài | RAL 3000 Flame Red Powder Powder Powder | ||
Production & Certification | BS EN 1866: 2007 |
